OEE has collaborated with Pneumofore to provide manufacturers with their UV Series Rotary Vane Vacuum Pumps, which have the Lowest Life Cycle cost in today’s market.
These pumps cover a wide vacuum range and offer single stage 250 to 7.160 m3/h [148 to 4.211 cfm] with the residual pressure of 0,5 to 450 mbar(a) [29,90 to 16,62 inHg V]. Capacity and residual pressure are extended with multiple stage machines. The family of UV pumps includes several versions for a wide variety of applications.
Key Benefits:
Suction volumes from 250 m3/h to 7.160 m3/h (Single stage). 99,95% maximum vacuum degree [0,5 mbar(a) residual absolute pressure] with performance curves constant up to 95%.
Reduced electric energy consumption when compared to liquid ring pumps with same nominal capacity. Up to 70% savings on replacements.
“Plug and play” pumps, easy to install and integrate.
Air cooling through an aluminium radiator and a temperature controlled fan. Water-free cooling prevents problems related to limestone, ambient temperature and unstable vacuum degree.
Special aluminum alloy vanes provide active sealing, avoiding efficiency loss and minimizing cost of operation and maintenance.
“Closed-loop” lubrication circuit ensures negligible coolant consumption.
Applications:
The UV Series is suitable for a wide range of industries, including:
- Glass forming
- Aluminium can manufacturing
- Drying and degassing processes
- Food processing and packaging
- Pasta production
- Metal and plastic container forming
- Pharmaceutical manufacturing
- Aerospace
- Bottling lines
And many more.
OEE provides full-service support, including:
- Technical consultation
- System design and specification
- Installation and commissioning
- After-sales support
- Spare parts
